THE BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA
THE 5
THE BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA
Discover all the data, specifications and dimensions of the BMW 5 Series Sedan here.
TECHNICAL DATA.

-
Weight
Weight Unladen weight EU in kg1,605Max. permissible weight in kg2,210Permitted load in kg670Permitted axle load front/rear in kg1,045/1,250Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves4/4Capacity in ccm1597Stroke/bore in mm75.6/82.0Engine power in kW (hp) at 1/min125 (170)/5,000-6,500Engine torque (Nm) at 1/min250/2,000-4,700Compression ratio : 18.9
-
Performance
Performance Top speed in km/h235Acceleration 0–100 km/h in s7.8Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km8.0-7.6Extra-urban in l/100 km5.9-5.6Combined in l/100 km6.5CO2 combined emissions in g/km149Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l68
-
Wheels
Wheels Tyre dimensions front225/55 R17 97YTyre dimensions rear225/55 R17 97YWheel dimensions and material front7.5 J x 17 inches, light-alloyWheel dimensions and material rear7.5 J x 17 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,605
|
Max. permissible weight in kg
|
2,210
|
Permitted load in kg
|
670
|
Permitted axle load front/rear in kg
|
1,045/1,250
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1597
|
Stroke/bore in mm
|
75.6/82.0
|
Engine power in kW (hp) at 1/min
|
125 (170)/5,000-6,500
|
Engine torque (Nm) at 1/min
|
250/2,000-4,700
|
Compression ratio : 1
|
8.9
|
Performance | |
---|---|
Top speed in km/h
|
235
|
Acceleration 0–100 km/h in s
|
7.8
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
8.0-7.6
|
Extra-urban in l/100 km
|
5.9-5.6
|
Combined in l/100 km
|
6.5
|
CO2 combined emissions in g/km
|
149
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
68
|
Wheels | |
---|---|
Tyre dimensions front
|
225/55 R17 97Y
|
Tyre dimensions rear
|
225/55 R17 97Y
|
Wheel dimensions and material front
|
7.5 J x 17 inches, light-alloy
|
Wheel dimensions and material rear
|
7.5 J x 17 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,615Max. permissible weight in kg2,220Permitted load in kg680Permitted axle load front/rear in kg1,065/1,255Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves4/4Capacity in ccm1,998Stroke/bore in mm94.6/82.0Engine power in kW (hp) at 1/min183 (249)/5,200-6,500Engine torque (Nm) at 1/min350/1,450-4,800Compression ratio : 110.2
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s6.1Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km8.0Extra-urban in l/100 km5.7Combined in l/100 km6.5CO2 combined emissions in g/km149Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l68
-
Wheels
Wheels Tyre dimensions front245/35 R20 95 Y XLTyre dimensions rear275/30 R20 97 Y XLWheel dimensions and material front8 J x 20 inches, light-alloyWheel dimensions and material rear9 J x 20 inches, ligth-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,615
|
Max. permissible weight in kg
|
2,220
|
Permitted load in kg
|
680
|
Permitted axle load front/rear in kg
|
1,065/1,255
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1,998
|
Stroke/bore in mm
|
94.6/82.0
|
Engine power in kW (hp) at 1/min
|
183 (249)/5,200-6,500
|
Engine torque (Nm) at 1/min
|
350/1,450-4,800
|
Compression ratio : 1
|
10.2
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
6.1
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
8.0
|
Extra-urban in l/100 km
|
5.7
|
Combined in l/100 km
|
6.5
|
CO2 combined emissions in g/km
|
149
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
68
|
Wheels | |
---|---|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
Wheel dimensions and material front
|
8 J x 20 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 20 inches, ligth-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,680Max. permissible weight in kg2,280Permitted load in kg675Permitted axle load front/rear in kg1,100/1,265Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves4/4Capacity in ccm1,998Stroke/bore in mm94.6/82.0Engine power in kW (hp) at 1/min185 (252)/5,200-6,500Engine torque (Nm) at 1/min350/1,450-4,800Compression ratio : 110.2
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s6.0Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km8.6Extra-urban in l/100 km6.1Combined in l/100 km7.0CO2 combined emissions in g/km160Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l68
-
Wheels
Wheels Tyre dimensions front245/35 R20 95 Y XLTyre dimensions rear275/30 R20 97 Y XLWheel dimensions and material front8 J x 20 inches, light-alloyWheel dimensions and material rear9 J x 20 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,680
|
Max. permissible weight in kg
|
2,280
|
Permitted load in kg
|
675
|
Permitted axle load front/rear in kg
|
1,100/1,265
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1,998
|
Stroke/bore in mm
|
94.6/82.0
|
Engine power in kW (hp) at 1/min
|
185 (252)/5,200-6,500
|
Engine torque (Nm) at 1/min
|
350/1,450-4,800
|
Compression ratio : 1
|
10.2
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
6.0
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
8.6
|
Extra-urban in l/100 km
|
6.1
|
Combined in l/100 km
|
7.0
|
CO2 combined emissions in g/km
|
160
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
68
|
Wheels | |
---|---|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
Wheel dimensions and material front
|
8 J x 20 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 20 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,705Max. permissible weight in kg2,270Permitted load in kg680Permitted axle load front/rear in kg1,130/1,280Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves6/4Capacity in ccm2,998Stroke/bore in mm94.6/82.0Engine power in kW (hp) at 1/min250 (340)/5,500-6,500Engine torque (Nm) at 1/min450/1,500-5,200Compression ratio : 111.0
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s5.1Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km9.3Extra-urban in l/100 km6.2Combined in l/100 km7.3CO2 combined emissions in g/km168Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l68
-
Wheels
Wheels Tyre dimensions front225/55 R17 97YTyre dimensions rear225/55 R17 97YWheel dimensions and material front7.5 J x 17 inches, light-alloyWheel dimensions and material rear7.5 J x 17 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,705
|
Max. permissible weight in kg
|
2,270
|
Permitted load in kg
|
680
|
Permitted axle load front/rear in kg
|
1,130/1,280
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
6/4
|
Capacity in ccm
|
2,998
|
Stroke/bore in mm
|
94.6/82.0
|
Engine power in kW (hp) at 1/min
|
250 (340)/5,500-6,500
|
Engine torque (Nm) at 1/min
|
450/1,500-5,200
|
Compression ratio : 1
|
11.0
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
5.1
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
9.3
|
Extra-urban in l/100 km
|
6.2
|
Combined in l/100 km
|
7.3
|
CO2 combined emissions in g/km
|
168
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
68
|
Wheels | |
---|---|
Tyre dimensions front
|
225/55 R17 97Y
|
Tyre dimensions rear
|
225/55 R17 97Y
|
Wheel dimensions and material front
|
7.5 J x 17 inches, light-alloy
|
Wheel dimensions and material rear
|
7.5 J x 17 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,765Max. permissible weight in kg2,370Permitted load in kg680Permitted axle load front/rear in kg1,180/1,290Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves6/4Capacity in ccm2,998Stroke/bore in mm94.6/82.0Engine power in kW (hp) at 1/min250 (340)/5,500-6,500Engine torque (Nm) at 1/min450/1,380-5,200Compression ratio : 111.0
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s4.7Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km9.8Extra-urban in l/100 km6.5Combined in l/100 km7.7CO2 combined emissions in g/km177Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l68
-
Wheels
Wheels Tyre dimensions front225/55 R17 97YTyre dimensions rear225/55 R17 97YWheel dimensions and material front7.5 J x 17 inches, light-alloyWheel dimensions and material rear7.5 J x 17 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,765
|
Max. permissible weight in kg
|
2,370
|
Permitted load in kg
|
680
|
Permitted axle load front/rear in kg
|
1,180/1,290
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
6/4
|
Capacity in ccm
|
2,998
|
Stroke/bore in mm
|
94.6/82.0
|
Engine power in kW (hp) at 1/min
|
250 (340)/5,500-6,500
|
Engine torque (Nm) at 1/min
|
450/1,380-5,200
|
Compression ratio : 1
|
11.0
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
4.7
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
9.8
|
Extra-urban in l/100 km
|
6.5
|
Combined in l/100 km
|
7.7
|
CO2 combined emissions in g/km
|
177
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
68
|
Wheels | |
---|---|
Tyre dimensions front
|
225/55 R17 97Y
|
Tyre dimensions rear
|
225/55 R17 97Y
|
Wheel dimensions and material front
|
7.5 J x 17 inches, light-alloy
|
Wheel dimensions and material rear
|
7.5 J x 17 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,945Max. permissible weight in kg2,480Permitted load in kg610Permitted axle load front/rear in kg1,250/1,310Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves8/4Capacity in ccm4,395Stroke/bore in mm88.3/89.0Engine power in kW (hp) at 1/min390 (530)/5,500-6,000Engine torque (Nm) at 1/min750/1,800-4,600Compression ratio : 110.5
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s3.8Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km14.8Extra-urban in l/100 km8.2Combined in l/100 km10.6CO2 combined emissions in g/km243Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l68
-
Wheels
Wheels Tyre dimensions front245/40 R19 98Y XLTyre dimensions rear275/35 R19 100Y XLWheel dimensions and material front8 J x 19 inches, light-alloyWheel dimensions and material rear9 J x 19 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,945
|
Max. permissible weight in kg
|
2,480
|
Permitted load in kg
|
610
|
Permitted axle load front/rear in kg
|
1,250/1,310
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
8/4
|
Capacity in ccm
|
4,395
|
Stroke/bore in mm
|
88.3/89.0
|
Engine power in kW (hp) at 1/min
|
390 (530)/5,500-6,000
|
Engine torque (Nm) at 1/min
|
750/1,800-4,600
|
Compression ratio : 1
|
10.5
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
3.8
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
14.8
|
Extra-urban in l/100 km
|
8.2
|
Combined in l/100 km
|
10.6
|
CO2 combined emissions in g/km
|
243
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
68
|
Wheels | |
---|---|
Tyre dimensions front
|
245/40 R19 98Y XL
|
Tyre dimensions rear
|
275/35 R19 100Y XL
|
Wheel dimensions and material front
|
8 J x 19 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 19 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight Unladen weight EU in kg1,635Max. permissible weight in kg2,260Permitted load in kg680Permitted axle load front/rear in kg1,055/1,295Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine Cylinders/valves4/4Capacity in ccm1,995Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min110 (150)/4,000-4,000Engine torque (Nm) at 1/min350/1,750-2,500Compression ratio : 116.5
-
Performance Top speed in km/h220Acceleration 0–100 km/h in s8.8Electrical engine top speed in km/h-
-
Fuel consumption Urban in l/100 km5.5Extra-urban in l/100 km4.7Combined in l/100 km5.0CO2 combined emissions in g/km132Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels Tyre dimensions front245/35 R20 95 Y XLTyre dimensions rear275/30 R20 97 Y XLWheel dimensions and material front8 J x 20 inches, light-alloyWheel dimensions and material rear9 J x 20 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,635
|
Max. permissible weight in kg
|
2,260
|
Permitted load in kg
|
680
|
Permitted axle load front/rear in kg
|
1,055/1,295
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1,995
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
110 (150)/4,000-4,000
|
Engine torque (Nm) at 1/min
|
350/1,750-2,500
|
Compression ratio : 1
|
16.5
|
Performance | |
---|---|
Top speed in km/h
|
220
|
Acceleration 0–100 km/h in s
|
8.8
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
5.5
|
Extra-urban in l/100 km
|
4.7
|
Combined in l/100 km
|
5.0
|
CO2 combined emissions in g/km
|
132
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
Wheel dimensions and material front
|
8 J x 20 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 20 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,670Max. permissible weight in kg2,270Permitted load in kg675Permitted axle load front/rear in kg1,065/1,295Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves4/4Capacity in ccm1,995Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min140 (190)/4,000 [148 (201)/4,000*]Engine torque (Nm) at 1/min400/1,750-2,500 [430/1,750-2,500*]Compression ratio : 116.5
-
Performance
Performance Top speed in km/h235Acceleration 0–100 km/h in s7.3Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km5.7-5.4Extra-urban in l/100 km4.8-4.4Combined in l/100 km5.0-4.8CO2 combined emissions in g/km131-125Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels
Wheels Tyre dimensions front245/35 R20 95 Y XLTyre dimensions rear275/30 R20 97 Y XLWheel dimensions and material front8 J x 20 inches, light-alloyWheel dimensions and material rear9 J x 20 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,670
|
Max. permissible weight in kg
|
2,270
|
Permitted load in kg
|
675
|
Permitted axle load front/rear in kg
|
1,065/1,295
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1,995
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
140 (190)/4,000 [148 (201)/4,000*]
|
Engine torque (Nm) at 1/min
|
400/1,750-2,500 [430/1,750-2,500*]
|
Compression ratio : 1
|
16.5
|
Performance | |
---|---|
Top speed in km/h
|
235
|
Acceleration 0–100 km/h in s
|
7.3
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
5.7-5.4
|
Extra-urban in l/100 km
|
4.8-4.4
|
Combined in l/100 km
|
5.0-4.8
|
CO2 combined emissions in g/km
|
131-125
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
Wheel dimensions and material front
|
8 J x 20 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 20 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,695Max. permissible weight in kg2,330Permitted load in kg680Permitted axle load front/rear in kg1,115/1,315Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves4/4Capacity in ccm1,995Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min140 (190)/4,000 [148 (201)/4,000*]Engine torque (Nm) at 1/min400/1,750-2,500 [430/1,750-2,500*]Compression ratio : 116.5
-
Performance
Performance Top speed in km/h232Acceleration 0–100 km/h in s7.3Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km5.9-5.8Extra-urban in l/100 km4.9-4.8Combined in l/100 km5.3-5.2CO2 combined emissions in g/km139-136Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels
Wheels Tyre dimensions front225/55 R17 97YTyre dimensions rear225/55 R17 97YWheel dimensions and material front7.5 J x 17 inches, light-alloyWheel dimensions and material rear7.5 J x 17 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,695
|
Max. permissible weight in kg
|
2,330
|
Permitted load in kg
|
680
|
Permitted axle load front/rear in kg
|
1,115/1,315
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1,995
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
140 (190)/4,000 [148 (201)/4,000*]
|
Engine torque (Nm) at 1/min
|
400/1,750-2,500 [430/1,750-2,500*]
|
Compression ratio : 1
|
16.5
|
Performance | |
---|---|
Top speed in km/h
|
232
|
Acceleration 0–100 km/h in s
|
7.3
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
5.9-5.8
|
Extra-urban in l/100 km
|
4.9-4.8
|
Combined in l/100 km
|
5.3-5.2
|
CO2 combined emissions in g/km
|
139-136
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
225/55 R17 97Y
|
Tyre dimensions rear
|
225/55 R17 97Y
|
Wheel dimensions and material front
|
7.5 J x 17 inches, light-alloy
|
Wheel dimensions and material rear
|
7.5 J x 17 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,735Max. permissible weight in kg2,355Permitted load in kg695Permitted axle load front/rear in kg1,135/1,315Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves6/4Capacity in ccm2,993Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min195 (265)/4,000-4,000Engine torque (Nm) at 1/min620/2,000-2,500Compression ratio : 116.5
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s5.7Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km7.0-6.1Extra-urban in l/100 km5.0-4.6Combined in l/100 km5.5-5.1CO2 combined emissions in g/km145-134Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels
Wheels Tyre dimensions front245/35 R20 95 Y XLTyre dimensions rear275/30 R20 97 Y XLWheel dimensions and material front8 J x 20 inches, light-alloyWheel dimensions and material rear9 J x 20 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,735
|
Max. permissible weight in kg
|
2,355
|
Permitted load in kg
|
695
|
Permitted axle load front/rear in kg
|
1,135/1,315
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
6/4
|
Capacity in ccm
|
2,993
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
195 (265)/4,000-4,000
|
Engine torque (Nm) at 1/min
|
620/2,000-2,500
|
Compression ratio : 1
|
16.5
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
5.7
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
7.0-6.1
|
Extra-urban in l/100 km
|
5.0-4.6
|
Combined in l/100 km
|
5.5-5.1
|
CO2 combined emissions in g/km
|
145-134
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
Wheel dimensions and material front
|
8 J x 20 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 20 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,795Max. permissible weight in kg2,410Permitted load in kg690Permitted axle load front/rear in kg1,185/1,325Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves6/4Capacity in ccm2,993Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min183 (249)/4,000-4,000Engine torque (Nm) at 1/min620/2,000-2,500Compression ratio : 116.5
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s5.4Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km7.3-6.6Extra-urban in l/100 km5.4-5.0Combined in l/100 km6.1-5.6CO2 combined emissions in g/km160-147Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels
Wheels Tyre dimensions front245/35 R20 95 Y XLTyre dimensions rear275/30 R20 97 Y XLWheel dimensions and material front8 J x 20 inches, light-alloyWheel dimensions and material rear9 J x 20 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,795
|
Max. permissible weight in kg
|
2,410
|
Permitted load in kg
|
690
|
Permitted axle load front/rear in kg
|
1,185/1,325
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
6/4
|
Capacity in ccm
|
2,993
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
183 (249)/4,000-4,000
|
Engine torque (Nm) at 1/min
|
620/2,000-2,500
|
Compression ratio : 1
|
16.5
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
5.4
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
7.3-6.6
|
Extra-urban in l/100 km
|
5.4-5.0
|
Combined in l/100 km
|
6.1-5.6
|
CO2 combined emissions in g/km
|
160-147
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
Wheel dimensions and material front
|
8 J x 20 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 20 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,830Max. permissible weight in kg2,450Permitted load in kg695Permitted axle load front/rear in kg1,210/1,325Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves6/4Capacity in ccm2,993Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min235 (320)/4,400Engine torque (Nm) at 1/min680/1,750-2,250Compression ratio : 116.5
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s4.7Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km7.3Extra-urban in l/100 km5.7Combined in l/100 km6.3CO2 combined emissions in g/km165Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels
Wheels Tyre dimensions front225/55 R17 97YTyre dimensions rear225/55 R17 97YWheel dimensions and material front7.5 J x 17 inches, light-alloyWheel dimensions and material rear7.5 J x 17 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,830
|
Max. permissible weight in kg
|
2,450
|
Permitted load in kg
|
695
|
Permitted axle load front/rear in kg
|
1,210/1,325
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
6/4
|
Capacity in ccm
|
2,993
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
235 (320)/4,400
|
Engine torque (Nm) at 1/min
|
680/1,750-2,250
|
Compression ratio : 1
|
16.5
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
4.7
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
7.3
|
Extra-urban in l/100 km
|
5.7
|
Combined in l/100 km
|
6.3
|
CO2 combined emissions in g/km
|
165
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
225/55 R17 97Y
|
Tyre dimensions rear
|
225/55 R17 97Y
|
Wheel dimensions and material front
|
7.5 J x 17 inches, light-alloy
|
Wheel dimensions and material rear
|
7.5 J x 17 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,935Max. permissible weight in kg2,470Permitted load in kg610Permitted axle load front/rear in kg1,230/1,325Luggage capacity min. (seats up or roof down) in l530Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg750Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg2,000
-
Engine
Engine Cylinders/valves6/4Capacity in ccm2,993Stroke/bore in mm90.0/84.0Engine power in kW (hp) at 1/min294 (400)/4,400-4,400Engine torque (Nm) at 1/min760/2,000-3,000Compression ratio : 116.0
-
Performance
Performance Top speed in km/h250Acceleration 0–100 km/h in s4.4Electrical engine top speed in km/h-
-
Fuel consumption
Fuel consumption Urban in l/100 km7.8-7.2Extra-urban in l/100 km5.7-5.6Combined in l/100 km6.4-6.2CO2 combined emissions in g/km169-164Electricity consumption, combined in kWh/100km-Tank capacity, approx. in l66
-
Wheels
Wheels Tyre dimensions front245/40 R19 98Y XLTyre dimensions rear275/35 R19 100Y XLWheel dimensions and material front8 J x 19 inches, light-alloyWheel dimensions and material rear9 J x 19 inches, light-alloy
-
Range and charging
Range and charging Electric range in km-Growth capacity of lithium-ion battery in kWh-Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h-
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min-Electric Engine torque (Nm) at 1/min-
-
Combined system power
Combined system power Combined power kW (hp)-Combined torque Nm-
Weight | |
---|---|
Unladen weight EU in kg
|
1,935
|
Max. permissible weight in kg
|
2,470
|
Permitted load in kg
|
610
|
Permitted axle load front/rear in kg
|
1,230/1,325
|
Luggage capacity min. (seats up or roof down) in l
|
530
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
750
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
2,000
|
Engine | |
---|---|
Cylinders/valves
|
6/4
|
Capacity in ccm
|
2,993
|
Stroke/bore in mm
|
90.0/84.0
|
Engine power in kW (hp) at 1/min
|
294 (400)/4,400-4,400
|
Engine torque (Nm) at 1/min
|
760/2,000-3,000
|
Compression ratio : 1
|
16.0
|
Performance | |
---|---|
Top speed in km/h
|
250
|
Acceleration 0–100 km/h in s
|
4.4
|
Electrical engine top speed in km/h
|
-
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
7.8-7.2
|
Extra-urban in l/100 km
|
5.7-5.6
|
Combined in l/100 km
|
6.4-6.2
|
CO2 combined emissions in g/km
|
169-164
|
Electricity consumption, combined in kWh/100km
|
-
|
Tank capacity, approx. in l
|
66
|
Wheels | |
---|---|
Tyre dimensions front
|
245/40 R19 98Y XL
|
Tyre dimensions rear
|
275/35 R19 100Y XL
|
Wheel dimensions and material front
|
8 J x 19 inches, light-alloy
|
Wheel dimensions and material rear
|
9 J x 19 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
-
|
Growth capacity of lithium-ion battery in kWh
|
-
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
-
|
Electric Engine torque (Nm) at 1/min
|
-
|
Combined system power | |
---|---|
Combined power kW (hp)
|
-
|
Combined torque Nm
|
-
|

-
Weight
Weight Unladen weight EU in kg1,845Max. permissible weight in kg2,420Permitted load in kg650Permitted axle load front/rear in kg1,120/1,405Luggage capacity min. (seats up or roof down) in l410Luggage capacity max. (seats down or roof up) in l-Trailer load (unbraked) in kg-Trailer load 8% (braked) in kg-Trailer load 12% (braked) in kg-
-
Engine
Engine Cylinders/valves4/4Capacity in ccm1,998Stroke/bore in mm94.6/82.0Engine power in kW (hp) at 1/min135 (184)/5,000-6,500Engine torque (Nm) at 1/min290/1,350-4,250Compression ratio : 111.0
-
Performance
Performance Top speed in km/h235Acceleration 0–100 km/h in s6.1Electrical engine top speed in km/h140
-
Fuel consumption
Fuel consumption Urban in l/100 km-Extra-urban in l/100 km-Combined in l/100 km2.0CO2 combined emissions in g/km46Electricity consumption, combined in kWh/100km15.6Tank capacity, approx. in l46
-
Wheels
Wheels Tyre dimensions front225/55 R17 97YTyre dimensions rear225/55 R17 97YWheel dimensions and material front7.5 J x 17 inches, light-alloyWheel dimensions and material rear7.5 J x 17 inches, light-alloy
-
Range and charging
Range and charging Electric range in km57Growth capacity of lithium-ion battery in kWh12.0Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h3.6
-
Electric engine
Electric engine Electric engine power kW (hp) at 1/min83 (113)/3,170Electric Engine torque (Nm) at 1/min250/0-3,170
-
Combined system power
Combined system power Combined power kW (hp)185 (252)Combined torque Nm420
Weight | |
---|---|
Unladen weight EU in kg
|
1,845
|
Max. permissible weight in kg
|
2,420
|
Permitted load in kg
|
650
|
Permitted axle load front/rear in kg
|
1,120/1,405
|
Luggage capacity min. (seats up or roof down) in l
|
410
|
Luggage capacity max. (seats down or roof up) in l
|
-
|
Trailer load (unbraked) in kg
|
-
|
Trailer load 8% (braked) in kg
|
-
|
Trailer load 12% (braked) in kg
|
-
|
Engine | |
---|---|
Cylinders/valves
|
4/4
|
Capacity in ccm
|
1,998
|
Stroke/bore in mm
|
94.6/82.0
|
Engine power in kW (hp) at 1/min
|
135 (184)/5,000-6,500
|
Engine torque (Nm) at 1/min
|
290/1,350-4,250
|
Compression ratio : 1
|
11.0
|
Performance | |
---|---|
Top speed in km/h
|
235
|
Acceleration 0–100 km/h in s
|
6.1
|
Electrical engine top speed in km/h
|
140
|
Fuel consumption | |
---|---|
Urban in l/100 km
|
-
|
Extra-urban in l/100 km
|
-
|
Combined in l/100 km
|
2.0
|
CO2 combined emissions in g/km
|
46
|
Electricity consumption, combined in kWh/100km
|
15.6
|
Tank capacity, approx. in l
|
46
|
Wheels | |
---|---|
Tyre dimensions front
|
225/55 R17 97Y
|
Tyre dimensions rear
|
225/55 R17 97Y
|
Wheel dimensions and material front
|
7.5 J x 17 inches, light-alloy
|
Wheel dimensions and material rear
|
7.5 J x 17 inches, light-alloy
|
Range and charging | |
---|---|
Electric range in km
|
57
|
Growth capacity of lithium-ion battery in kWh
|
12.0
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
3.6
|
Electric engine | |
---|---|
Electric engine power kW (hp) at 1/min
|
83 (113)/3,170
|
Electric Engine torque (Nm) at 1/min
|
250/0-3,170
|
Combined system power | |
---|---|
Combined power kW (hp)
|
185 (252)
|
Combined torque Nm
|
420
|
Fuel consumption and CO2 emissions.
-
* with mild hybrid technology
BMW 540i Sedan:
Fuel consumption in l/100 km (combined): 7.3
CO2 emissions in g/km (combined): 168The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.
The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
